A3
Micro ATX
Specs
Model | A3 | |
---|---|---|
Model Number | IW-CS-A3BLK-1AM120S IW-CS-A3WHI-1AM120S |
|
Colors | Black White |
|
Case Type | Micro-ATX Tower | |
Materials | SECC, Tempered Glass, Aluminium, PC-ABS | |
M/B Compatibility | Micro-ATX, Mini-ITX | |
Expansion Slots | 4 x PCI-E | |
Maximum Compatibility | VGA Card Length: 340 mm CPU Heatsink Height: 162 mm |
|
I/O Ports | 1 x USB 3.2 Gen 2x2 Type-C 2 x USB 3.2 Gen 1 HD Audio Combo (CTIA – SPK/Mic) |
|
Internal Drive Bays | 2 x 3.5" / 2.5" 1 x 2.5" |
|
Thermal Solution Compatibility |
Air Cooling Fans: |
|
Power Supply Compatibility | PSII: ATX12V - Length between 140 - 200 mm (PSUs longer than 170 mm will need to build with GPUs 280 mm or shorter) |
|
Product Dimensions (L x W x H) |
401 x 215 x 347 mm 15.8 x 8.5 x 13.7" |
|
Package Dimensions (L x W x H) |
473 x 277 x 422 mm 18.6 x 10.9 x 16.6" |
|
Net Weight | 5.24 kg / 11.55 lbs | |
Gross Weight | 6.25 kg / 13.78 lbs | |
* Number of fans pre-installed may vary based on different regions. * InWin's products comply with RoHS regulation. * Specifications may vary based on different regions. |
Model | Mercury AM120S | |
---|---|---|
Quantity Included | Single Pack | |
Model Number | IW-FN-AM120S-1PK | |
Colors | Black | |
Fan Size | 120 x 120 x 20 mm | |
Materials | PBT, PC | |
Rated Voltage | DC 12V | |
Rated Power | 1.8W | |
Rated Current | 0.15A | |
ARGB Rated Voltage | DC 5V | |
ARGB Rated Power | 1.4W | |
ARGB Rated Current | 0.28A | |
Speed Mode | PWM 400 - 2000 +/- 10% RPM | |
Air Flow | 60.71 CFM | |
Air Pressure | 2.72 mm / H2O | |
LED | Addressable RGB | |
Connector (Fan to Fan) | Non-Modular Cables | |
Connector to M/B | 4-Pin (12V, PWM), 3-Pin (5V, ARGB) | |
Noise Level | 17 - 29 dB(A) | |
Bearing Type | Long Lifespan Sleeve Bearing | |
MTBF | >60,000 hrs. | |
Net Weight | 138 g / 0.3 lbs | |
Gross Weight | 184 g / 0.4 lbs | |
Package Dimension (L x W x H) |
165 x 125 x 25 mm 6.49 x 4.92 x 0.98" |
|
Warranty | 3 Years | |
* InWin’s products comply with RoHS regulations. * Specifications may vary based on different regions. |
Sleek, Minimalistic Design
Fit for High-end Graphics Card
Powerful Cooling
Go Screwless!
Outstanding I/O
Slim Silent Fan Mercury AM120S
Components
Download
Become a Fan of InWin’s Case Fans!
InWin's case fans are both aesthetically pleasing and practical. There are different series of case fans that meet different user requirements. Some of InWin’s fans are daisy-chainable and some are not. So, take a look and check out which InWin fans match your needs
Non-Modular Cable |
Neptune Pure |
Sirius Pure |
Luna AL120 |
Mercury AM120S |
Sirius Loop |
Jupiter Series |
---|---|---|---|---|---|---|
Neptune AN Series |
Neptune DN Series |
Neptune DN PRO Series |
Sirius Extreme Pure |
Sirius Extreme |
||
Modular ARGB Type 1 |
Aurora |
EGO |
||||
Modular ARGB Type 2 |
Crown Series |
Saturn Series |
||||
Modular RGB |
Polaris RGB Series |
Polaris AluminumRGB Series |
InWin’s Fans Compatibility Note:
1. Do not chain up your fans with other fans in with different cables types.
2. ARGB fans and RGB fans are not compatible with each other.
