€229.99
No reviews
No reviews
SKU: IW-CS-POCONEBLK

Mini ITX

Featuring 3 mm-thick aluminium and frosted acrylic panels, POC ONE is a mini-ITX chassis with a variety of combined materials, maintaining the DIY experience for PC enthusiasts.

color:Black
Quantity:

  1. All-In-One Structure
  2. Dual-Orientation
  3. Supports High-end GPUs
  4. Interactive Assembly Guide

Specs

Model POC ONE
Model Number IW-CS-POCONEBLK
IW-CS-POCONESIL
Colors Black, Silver
Case Type Mini-ITX Tower
Materials Aluminium, SGCC, PMMA
M/B Compatibility Mini-ITX
Expansion Slots 3 x PCI-E
(Supports 3.5-Slot GPU, PCI-E Riser Cable Included)
Maximum Compatibility GPU Length: 335 mm
GPU Thickness: 62 mm
CPU Heatsink Height: 140 mm
I/O Ports 1 x USB 3.2 Gen 2x2 Type-C
2 x USB 3.2 Gen 1
HD Audio Combo (CTIA – SPK/Mic)
Internal Drive Bays 1 x 2.5"
Thermal Solution Compatibility Air Cooling Fans:
Side: 1 x 120 mm
Rear: 2 x 120 mm
(1 InWin Jupiter AJ120 Fan Included)
Water Cooling Radiator:
Rear: 1 x 240 mm
Power Supply Compatibility PSII: ATX12V
- Length up to 160mm
Product Dimensions
(L x W x H)		 302 x 210 x 411 mm
11.9 x 8.3 x 16.2"
Package Dimensions
(L x W x H)		 520 x 510 x 120 mm
20.5 x 20.1 x 4.7"
Net Weight 4.4 kg / 9.7 lbs
Gross Weight 5.4 kg / 11.9 lbs
* InWin's products comply with RoHS regulation.
* Specifications may vary based on different regions.
Model Jupiter AJ120
Model Number IW-FN-AJ120-1PK
Fan Size 120 x 120 x 25 mm
Materials PBT, PC
Rated Voltage DC 12V
Rated Power 2.4W
Rated Current 0.20A
ADD RGB Rated Voltage DC 5V
ADD RGB Rated Power 1.1W
ADD RGB Rated Current 0.22A
Speed Mode PWM 500 - 1800 +/- 10% RPM
Air Flow 70.32 CFM
Air Pressure 2.62mm / H2O
LED Addressable RGB
Connector (Fan to Fan) Non-Modular Cables
Connector to M/B 4-Pin (12V), 3-Pin (ARGB, 5V)
Noise Level 35 dB(A) (Max.)
Bearing Type Long Lifespan Sleeve Bearing
Net Weight 200 g / 0.44 lbs
Package Dimensions (L x W x H) 125 x 30 x 185 mm
4.92 x 3.14 x 7.28"
Warranty 2 Years
* InWin's products comply with RoHS regulation.
* Specifications may vary based on different regions.

All is One

POC ONE’s panels are pre-linked to form into one-piece. Assemble the structure with just a few screws.

Theme of Color Scheme

POC ONE comes with two color options – black or silver. Both the stylish black and the classy aluminium panels add a distinct touch to the home or office.

High Compatibility

A mini-ITX chassis that offers the flexibility to accommodate 240 mm radiator and a high-end GPU up to 335 mm.

Easy Breezy

The rounded ventilation holes on the POC ONE serves not only for aesthetics, but also to enhance airflow.

Flat Packaging

POC ONE maintains the flat-packed design to reduce packaging and box size while mitigating environmental impact.

Components

1. POC ONE Chassis
2. POC PCI-E 4.0 Riser Cable x 1
3. I/O Module x 1
4. Jupiter AJ120 1-Pack x 1
5. Accessories box x 1
6. POC ONE Sticker Pad x 1
7. M/B Anti-Dust Cover x 2

Become a Fan of InWin’s Case Fans!

InWin's case fans are both aesthetically pleasing and practical. There are different series of case fans that meet different user requirements. Some of InWin’s fans are daisy-chainable and some are not. So, take a look and check out which InWin fans match your needs

Non-Modular Cable
4 Pin (PWM, 12V), 3 Pin (ARGB, 5V)

Sirius Loop

Jupiter Series

Sirius Pure

Luna AL120

Mercury AM120S

Sirius Extreme

Sirius Extreme Pure

Neptune AN Series

Neptune DN Series

Neptune DN PRO Series

Modular ARGB Type 1
6-Pin Modular (PWM + ARGB)

Aurora

EGO

Modular ARGB Type 2
6-Pin Modular (PWM + ARGB)

Crown Series

Saturn Series

Type-C Modular Cable
(PWM + ARGB)

Lynx Series

Modular RGB
8-Pin Modular (PWM + RGB)

Polaris RGB Series

Polaris AluminumRGB Series

InWin’s Fans Compatibility Note:
1. Do not chain up your fans with other fans in with different cables types.
2. ARGB fans and RGB fans are not compatible with each other.
